Brand: Ascendo
Speakers

Ascendo The 12 PRO Active EXT Wedge

د.إ35,300

23 people are viewing this right now
17 products sold in last 1 hour
Selling fast! Over 6 people have this in their carts
Categories: , , , ,

The design objective for this model was to offer a pre-angled version of The12 PRO ACTIVE EXT that can be installed in multiple locations where angling the speakers is mandatory. Such locations include but are not limited to front wide, Atmos and DTS top front and rear, front or rear high surrounds, side surrounds etc.

The driver design is perfect for wide angle axi-symmetric radiation to cover a large listening area, with its 30-degree pre-angle meeting the requirements of most 3D home theater builds according to current CEDIA, Dolby and DTS specs.

The very flexible speaker mounting and orientation options ensure best possible localization, immersion, and tonal balance at the main listening position while minimizing localization shifts for side seats.

The12 PRO ACTIVE EXT WEDGE is an enormously dynamic and powerful speaker. Its high efficiency and high-power handling allow it to reach reference volume levels and obtain an impressive cinema sound experience even with low amplifier power.

Specifications

Speaker type Time coherent  12″  point-Source with AIA Speaker Management Technology
Enclosure type Vented
Passive / Active Active, 2Ch DSP + 2Ch Amplifier are required
Recommended Amplifiers low-mid 85 Vrms, 120 Vpk, 10,6 A; high 44 Vrms, 62Vpk, 5,5 A; equivalent to LF 900W@8Ω, HF 240W@ 8Ω
Recommended ASCENDO Amplifiers DNA2250.2
Cont./peak output 127 dB cont. / 130 dB peak
Frequency Range 65 Hz to 21 kHz
Woofer 12″, 300mm
Tweeter 1.4″ (Throat) compression driver
Directivity Horizontal x Vertical in Deg° 85° x 85°
Input Terrminal Neutrik Speakon
Enclosure Innenverstrebtes Birkensperrholz
Width 19,69″ / 500 mm Horizontal
Height 17,72″ / 450 mm Horizontal
Depth With Plug 7,11-11,74″ / 180,61 – 228,17 mm, Angle 15°
Depth grill  0,39″ / 10 mm
Weight 46,96 lbs / 21,3 kg
Finish Structural paint black
Custom colour options Genuine piano lacquer (12 layers): matt lacquer: colour of choice, other finishes upon request
Shape customization Possible, upon request
Mounting 4 x  wall brackets for horizontal and vertical installation,  VESA 200 mounting option
