Bolt OBD GPS Tracker for Fleet Management
Plug-and-play OBDII GPS tracking device with backup battery for real-time vehicle and fleet management
- High-precision GPS tracking device plugs into existing OBDII ports for real-time tracking
- Internal backup battery – if the device is removed from power it will continue to track for a period of time
- Critical ‘unplugged/power loss’ alerts to notify users of device removal, tampering, unauthorized trips, or theft
- Speeding, harsh braking and cornering, accident and rollover detection
- Electronic Odometer Calculations
- Accelerometer for adaptive and movement-based tracking
- Plug and play or splitter installation options
Bolt2 Features
High Precision
GPS/GLONASS/Galileo positioning systems are used simultaneously for enhanced accuracy and faster fixes.
Plug and Play
Quickly and easily plug the Bolt2 OBD GPS Tracker into existing OBDII ports or install covertly with a splitter.
Real-Time Tracking
The Bolt2 OBD GPS Tracker remains continuously connected while on the move for real-time vehicle tracking.
Backup Battery
Features a 200mAh LiPo internal backup battery pack enabling critical ‘unplugged/power loss’ alerts to notify users of device removal or tampering.
Theft Recovery
Switch to Recovery Mode in the case of theft or loss to activate real-time tracking for asset retrieval.
Driver Safety & Behavior
Monitor speeding, harsh acceleration, braking, cornering, idling, and more to improve safety and prevent unnecessary wear on vehicles.
Accident & Rollover Detection
Configure accident and rollover alerts triggered by extreme changes in velocity and orientation of vehicle.
Run Hour Monitoring
Calculate run hours and distance traveled (odometer) to understand and optimize vehicle utilization.
Preventative Maintenance
Set reminders based on distance traveled and run hours to reduce maintenance and repair costs.
Geofencing
Create custom geofences and alerts if an asset enters or leaves specific locations.
Flexible Configuration
Configure device parameters such as heartbeat rate, movement and accelerometer settings, and more to fit any tracking application.
AES-256 Encryption
Military-level AES-256 Encryption to protect the integrity and confidentiality of your telematics data.
| Manufacturer | Digital Matter |
|---|---|
| Brand | Digital Matter |
| CONNECTIVITY | LTE-M / NB-IoT versions |
| SIM Size & Access | Internal Nano 4FF SIM |
| Chipset | UBLOX EVA-M8Q with TCXO |
| Constellation | Concurrent GPS / GLONASS / Galileo |
| Channels | 72 Channel High Sensitivity Receiver |
| Tracking Sensitivity | -167dBm tracking performance |
| Location Accuracy | ~2.0m CEP, 50%, 24 hours static, GPS, SBAS, -130dBm, > 6SVs |
| GNSS Assistance | GNSS almanac and ephemeris data for greater sensitivity and position accuracy |
| Low Noise Amplifier | GPS signals are filtered and boosted by a low-noise amplifier (LNA) allowing operation where other units fail |
| Cell Tower Location | Cell tower location fallback for positioning when GPS can’t get a fix |
| Input Voltage | 8-36V DC (max) |
| Self-Resetting Fuse | Built-in self-resetting fuse makes installation simple and safe. Stringent automotive power “load dump” tests are conducted to ensure operation in the harshest electrical systems. |
| Operating Current | ~25/50mA when moving |
| Sleep Current | <1mA |
| Back-Up Battery | 200mAh LiPo internal backup battery pack |
| Dimensions | 71 x 46 x 24 mm (2.8 x 1.81 x 0.94″) |
| Weight | 48 g (1.69 oz) |
| Housing | ABS Polycarbonate Plastic |
| Installation | OBDII standard connector draws power from the OBDII port to operate |
| Operating Temperature | -30°C to +60°C (connected to external power) At +40°C the internal backup battery will not be charged as a safety precaution . |
| Cellular Antenna | Internal |
| GPS Antenna | Internal |
| 3-Axis Accelerometer | 3-Axis Accelerometer to detect movement, high G-force events, and more |
| Flash Memory | Store weeks of records if device is out of cellular coverage. Storage capacity for over 10 days of continuous 30-second logging. |
| On-Board Speed & Heading | The device continuously monitors speed and heading, allowing for over-speed alerts as well as updates on speed and heading changes |
| On-Board Temperature | The device reports internal temperature and prevents the internal battery charging in extreme temperatures. Internal temperature provides an indication of ambient temperature but may not always be precise. |
| Auto-APN | Auto-APN allows the device to analyze the SIM card and select the correct APN details from a list that is pre-loaded in the device’s firmware |
| Accident & Rollover Detection | Configure accident and rollover alerts triggered by extreme changes in velocity and orientation of vehicle or equipment. Second-by-second GPS data is saved on the device’s flash memory, with a capacity of approximately 2 hours of data. In the event of an accident, a subset of the data (60 seconds before / 10 seconds after) is uploaded to the server automatically (if configured) or can be requested manually for a detailed reconstruction of the incident. |
| Driver Safety & Behavior | Monitor speeding, harsh acceleration, braking, cornering, idle times and more to improve safety and prevent unnecessary wear on vehicles |
| Geofence Alerts | The server can use device location to create geofences and alerts if an asset enters or leaves designated locations |
| Preventative Maintenance | Set reminders based on distance traveled and run hours to reduce maintenance and repair costs |
| Real-Time Tracking | Device remains continuously connected while on the move for real-time asset tracking |
| Run Hour Monitoring | Calculate run hours and distance traveled (odometer) to understand and optimize asset utilization |
| Theft Recovery | Switch to Recovery Mode in the case of theft or loss to activate real-time tracking for asset retrieval |
| Diagnostic LED | Diagnostic LED indicates operation status |
| Tamper/Removal Detection | Critical ‘unplugged/power loss’ alerts to notify users of device removal, tampering, unauthorized trips, or theft |
| Flexible Configuration | Configure device parameters such as position update rate, movement and accelerometer settings, and more to fit any tracking application. |
| Device Management Platform | Manage, monitor, configure, debug, update, and restart devices remotely from our cloud-based device management system |
| Configuration App | Manage device firmware updates and parameters via DM-Link provisioning tool. |
| INTEGRATION | TCP Direct or HTTPS Webhook |
| Data Security | Military-level AES-256 Encryption from device to Device Management Platform to protect the integrity and confidentiality of telematics data. Data forwarded to third-party systems is sent via HTTPS for end-to-end security |
| Warranty | Two-year manufacturer’s warranty. |
