G62 LoRaWAN® – LoRa Vehicle Tracking Device for Fleet Management

22 people are viewing this right now
6 products sold in last 4 hours
Selling fast! Over 10 people have this in their carts

Robust and ultra-rugged vehicle and heavy equipment tracking device with inputs/outputs for fleet management, equipment monitoring on LoRaWAN® networks

  • High-precision GPS/GLONASS tracking device
  • Weatherproof and ultra-rugged IP67 Housing
  • Internal Backup Battery in case of loss of power or tampering
  • 1 x Analog Inputs, 2 x Digital Inputs, 1 x Switched Ground Digital Output, 1 x Ignition Digital Input
  • On-device Odometer Readings
SKU: G62-LORAWAN Categories: , , , Tags: , , , ,

G62 LoRaWAN® Features

High Precision GPS

GPS and GLONASS positioning systems are used simultaneously with a 72 channel high sensitivity receiver (-167dBm) for enhanced accuracy and faster fixes.

Global Connectivity

Highly sensitive radio receiver is available in 868 or 902 – 928MHz versions for global LoRaWAN® connectivity.

Rugged & Weatherproof

IP67 rated housing ensures the device can withstand fine dust, high-pressure spray, submersion for 30 minutes in 1m of water, and extreme temperatures.

Inputs

Interface with a range of devices and switches to fit any application including seatbelt detection, door open/close monitoring, and more.

Accelerometer

3-Axis Accelerometer to detect movement.

Run Hour Monitoring

Calculate run hours and distance travelled (odometer) to understand and optimize asset utilization.

Flexible Configuration

Configure device parameters such as heartbeat rate, movement and accelerometer settings, and more to fit any tracking application.

AES-128 Encryption

LoRaWAN® networks use AES-128 Encryption to protect the integrity of your telematics data.

G63 Vehicle gps tracker

Manufacturer

Digital Matter
Brand

Digital Matter
CONNECTIVITY

Lorawan
Chipset

uBlox EVA-M8
Constellation

Concurrent GPS / GLONASS
Channels

72 Channel High Sensitivity Receiver
Tracking Sensitivity

-167dBm tracking performance
Location Accuracy

~2.0m CEP, 50%, 24 hours static, GPS, SBAS, -130dBm, > 6SVs
Low Noise Amplifier

GPS signals are filtered and boosted by a SAW filter and low-noise amplifier (LNA) allowing operation where other units fail
LoRaWAN® Geolocation

LoRaWAN gateway geolocation fallback when there is no GNSS (planned)
Input Voltage

8-36V DC (max)
Self-Resetting Fuse

Built-in self-resetting fuse makes installation simple and safe. Stringent automotive power “load dump” tests are conducted to ensure operation in the harshest electrical systems.
Operating Current

~25/50mA when moving ~150mA battery charging
Sleep Current

<1mA
Back-Up Battery

1100mAh LiPo internal backup battery pack
Dimensions

126 x 80 x 27 mm (4.96 x 3.15 x 1.06″)
Weight

171 g (6.03 oz)
Housing

Ultra-Rugged Nylon Glass
IP Rating

IP67 rated housing ensures device can withstand fine dust, high-pressure spray, submersion for 30 mins in 1m of water, and extreme temperatures
Installation

7 wire harness 1m Length
Operating Temperature

-20°C to +60°C
GPS Antenna

Internal
3-Axis Accelerometer

3-Axis Accelerometer to detect movement
Diagnostic LED

Diagnostic LED indicates operation status
Analog Inputs

1 x 0-30V Analog Input, Auto Ranging, 12-bit ADC 0-5V range: 1.22mV precision 0-30V range: 7.32mV precision
Digital Inputs

2 x Digital Inputs with configurable pull-up/down 0-48V DC input range On/Off thresholds: Pull-up enabled: low at 0.8V, high at 1.0V Pull-down enabled: low at 2.0V, high at 2.4V
Digital Outputs

1 x Switched Ground Digital Output Can be toggled via downlink.
Ignition

1 x dedicated ignition Digital Input 0-48V DC 5V on/off threshold
Geofence Alerts

The server can use device location to create geofences and alerts if an asset enters or leaves designated locations
Run Hour Monitoring

Calculate run hours and distance traveled (odometer) to understand and optimize asset utilization
Flexible Configuration

Configure device parameters such as position update rate, movement and accelerometer settings, and more to fit any tracking application.
Configuration App

Manage device firmware updates and parameters via DM-Link provisioning tool. Some parameters can be changed via downlink.
INTEGRATION

Easy integration with comprehensive documentation and a flexible and open payload format
SECURITY

LoRaWAN networks use AES-128 Encryption so your data is protected
Warranty

Two-year manufacturer’s warranty.
