SVS Prime Tower Floorstanding Speakers (Piano Black)
The Prime Tower speakers set the bar for sound quality and high-end appeal among tower speakers anywhere near the price. The reference-grade SVS floorstanding speaker is amazingly transparent, with a broad, stable soundstage and sharp imaging of voices and instruments, all punctuated by deep yet accurate low frequency extension.
Features:
- 1” Aluminum Dome Tweeter with FEA- Optimized diffuser
- Dual 6.5″ Woofers
- 4.5″ Midrange Driver
- Dual 1.7” wide-flared rear-firing ports
- Single set of 5-way binding posts
- Cloth grille with pin/cup retention system
- Overall Dimensions: 36.6″ (H) X 8″ (W) X 11.6″ (D) (includes grille and feet)
SVS Prime Tower Floor Standing Speakers
The Prime Tower Floor Standing Speaker is a reference-grade loudspeaker with pinpoint accuracy, exceptional tonal balance, effortless bass response and all the qualities of the best high-end floorstanding speakers available. It’s truly a stunning achievement for two-channel audiophile or surround sound home theater systems alike, especially considering the benchmark setting performance value.
Specification:
FREQUENCY RESPONSE : 30 Hz-25 kHz (±3 dB)
SENSITIVITY : 87 dB (2.83V @ 1 meter full-space, 300-3kHz)
POWER HANDLING (CONT/PEAK) : Recommended Amplifier 20-250 watts
NOMINAL IMPEDANCE : 8 ohms Compatible
CROSSOVER FREQUENCY : Midrange-tweeter : 2100hz, top woofer-midrange : 350hz, bottom woofer low pass : 165hz
HIGH FREQUENCY DRIVER : 1” Aluminum dome tweeter
LOW FREQUENCY DRIVER : Dual 6.5″ woofers
MIDRANGE FREQUENCY DRIVER : 4.5″ driver
ENCLOSURE MATERIAL : MDF
ENCLOSURE TYPE : Dual 1.7″ wide flared rear-firing ports
INPUTS : Single set of 5 way binding posts
HEIGHT : 36.6″
WIDTH : 8″
DEPTH : 11.6″
PRODUCT WEIGHT LBS : 46.3 lb per Speaker
FINISHES : Piano Gloss Black
SVS Prime Tower Speakers Highlights
1. Frequency Response / Acoustic Data:
- Rated bandwidth: 30 Hz-25 kHz (±3 dB)
- Nominal impedance: 8 ohms.
- Sensitivity: 87 dB (2.83V @ 1 meter full-space, 300-3kHz)
- Recommended amplifier power: 20-250 watts.
2. Speaker Specs:
- Floor Standing Tower Loudspeaker
- Black ash and piano gloss black finish options
- Single set of 5-way binding posts
- Dual 1.7” wide-flared rear-firing ports
- Cloth grille with pin/cup retention system
- Elastomer stick-on bumper feet (adds 3mm to height)
- Spiked metal screw-in feet included – adjustable for level
- Cabinet Dimensions: 36″ (H) X 8″ (W) X 11.1″ (D)
- Overall Dimensions: 36.6″ (H) X 8″ (W) X 11.6″ (D) (includes grille and feet)
- Shipped Dimensions: 41.3″ (H) X 14.1″ (W) X 17.3″ (D)
- Weight: 40.1 pounds
- Shipped Weight: 46.3 pounds
3. Driver Specs:
1” Aluminum Dome Tweeter:
- FEA-optimized diffuser for airy and unveiled presentation
- Aluminum dome for exceptional transient response
4.5” Midrange Driver:
- Polypropylene cone for excellent stiffness/mass ratio and pistonic behavior
- Aluminum shorting ring to reduce gap inductance, lower distortion, and enhance high frequency response
- Cast ABS-fiberglass composite basket ensures precision component alignment and excellent thermal transfer
- Vented voice coil former minimizes air compression artifacts
Dual 6.5” Woofers:
- Long stroke motor and suspension for high output
- Polypropylene cone for excellent stiffness/mass ratio and pistonic behavior
- Aluminum shorting ring to reduce gap inductance, lower distortion, and enhance high frequency response
- Cast ABS-fiberglass composite basket ensures precision component alignment and excellent thermal transfer
- Vented voice coil former minimizes air compression artifacts
4. Crossover & Cabinet Specs:
Crossover:
- 3.5-way crossover with premium-grade capacitors, air-core inductors and heavy-trace printed circuit boards.
- Tapered woofer array optimizes the transition to the midrange driver and reduces vertical axis lobing
- Midrange-to-tweeter crossover: 2.1 kHz (12 dB/octave slopes)
- Top woofer (Combined Woofer) to midrange crossover frequency: 350 Hz (12 dB/octave slopes).
- Bottom woofer low pass frequency: 165 Hz (customized filter Q and slope)
Cabinet:
- Separate sealed midrange enclosure shifts standing waves beyond the driver pass band, improving sound quality
- Separate woofer enclosures with optimized port tuning frequencies for smooth and accurate bass response
- Acoustically transparent and FEA optimized grilles minimize diffraction
- Chamfered front baffle and flush-mounted drivers reduce edge diffraction and improved on-axis high frequency response
- FEA-optimized cabinet and bracing eliminates resonances
| Weight | 42 kg |
|---|---|
| Dimensions | 43.94 × 35.81 × 104.9 cm |
| Frequency Response | 30 Hz-25 kHz (±3 dB) |
| Sensitivity | 87 dB (2.83V @ 1 meter full-space, 300-3kHz) |
| Power Handeling (Cont/Peak) | Recommended Amplifier 20-250W |
| Nominal Impedance | 8 ohms compatible |
| Crossover Frequency | Midrange-to-Tweeter: 2.1 kHz (12 dB/octave slopes) Top Woofer to Midrange: 350 Hz (12 dB/octave slopes) Bottom Woofer: 165 Hz (customized filter Q and slope) |
| High Frequency Driver | 1” Aluminum Dome Tweeter with FEA- Optimized diffuser |
| Midrange Driver | 4.5” Midrange Driver |
| Low Frequency Driver | Dual 6.5" Woofers |
| Enclosure Material | MDF |
| Enclosure Type | Bass-Reflex via rear-firing ports Separate sealed midrange enclosure Separate woofer enclosure |
| Inputs | Single set of 5-way binding posts |
| Height | 36.6" |
| Width | 8" |
| Depth | 11.6" |
| Weight | 40.1 lbs |
| color | Piano Black |
| Brand | SVS |
